The Hydraulic Release Rail Brakes (RB) feature spring-based braking on the top of the rail, balanced braking force, and oversized, longer-lasting springs for reduced maintenance. Braking force up to 300 kN.

> Largest installation clearance (“16mm air gap”) for larger rail height deviation.
> Brake units longer stroke (35 to 45mm) to accommodate rail vertical fluctuation.
> Oversized springs for greater spring life and reduced maintenance.
> Flow control valve installed on a brake for controlled setting time.
> IFM Proximity switch for release indication signal.
> Brake shoes easily removeable and replaceable.
> Brakes are fabricated from high quality structural steel.
> ISO 12944-9 C4 Corrosion protection paint system for coastal areas.
> Emergency release Spacers.
> Installation bolts can be used as Emergency Release Bolts.
> Manual release (hand pump installed on the Hydraulic Power Unit).

> Ship to shore cranes
> Automated stacking cranes
> Wide Span Cranes
> Rail Mounted Gantry Cranes
> Log Handling Cranes
> Ship Loaders
